UTP Coax to BNC Video Balun Male Screw Type

This UTP Coax to BNC Video Balun lets you transmit a standard analog video signal over twisted-pair (UTP) cabling instead of bulky coaxial cable. With its male screw-type BNC connector, it plugs directly onto a camera or DVR port for a secure, tool-free connection—ideal for clean, cost-effective CCTV and surveillance installations.

Key specifications

• Connector type: Male BNC (screw type) on one end; UTP terminal block on the other
• Transmission medium: Unshielded twisted pair (UTP) cable, e.g., Cat5e/Cat6
• Signal type: Analog composite video (CVBS)
• Application: Connects a coax-based camera or device to a UTP run, or converts a UTP signal back to BNC at the receiver end
• Design: Passive balun—no external power required
• Mounting: Direct screw-on to BNC female port; compact, low-profile housing

Typical use

• Extending or rerunning CCTV video over existing network cabling
• Reducing cable cost and weight in multi-camera installations
• Converting a BNC camera output to UTP for longer, interference-resistant runs
